Grooved Tees

A grooved tee is a type of pipe fitting used to connect three pipes at a T-junction. It is named after the grooves present at the end of each pipe, which allow for quick and easy connection using mechanical couplings. Grooved tees are commonly used in various industrial applications that require high reliability and efficiency of the piping system.

They are made from a variety of materials, including carbon steel, stainless steel, and ductile iron, and come in different sizes and pressure ratings to cater to specific applications. Additionally, grooved tees are available in different configurations, such as equal tee and reducing tee, to accommodate different pipe diameters and flow rates. Overall, grooved tees are a popular choice for connecting pipes in industrial and commercial applications as they provide a fast, simple, and reliable way to join pipes together.

Pipe Couplings and Fittings
    1. Mechanical Tee Grooved Outlet View More
    2. Mechanical Tee Grooved Outlet Mechanical tee grooved outlet consist of upper and lower plates, a gasket, and bolts/nuts, providing a simple and fast method for branch connection.
      Available sizes
      Available sizes: 2×1 inch~10×4 inch |DN50×25~DN250×65
      Working pressure
      Working pressure: 300 PSI
      Certificate
      Certificate: FM/UL/CE certified
    1. Mechanical Tee Threaded Outlet View More
    2. Mechanical Tee Threaded Outlet Mechanical tees threaded outlet consist of upper and lower housings, a gasket, and bolts/nuts, providing a simple and fast method for branch connection.
      Available sizes
      Available sizes: 2×1 inch~10×4 inch |DN50×25~DN250×65
      Working pressure
      Working pressure: 300 PSI
      Certificate
      Certificate: FM/UL/CE certified
    1. U-Bolt Mechanical Tee View More
    2. U-Bolt Mechanical Tee U-bolt mechanical tee consists of an upper housing and U-bolt/nuts, allowing for quick and simple connection of branch pipes to the main pipeline.
      Available sizes
      Available sizes: 1×1/2 inch~3×1 inch |DN25×15~DN80×25
      Working pressure
      Working pressure: 300 PSI
      Certificate
      Certificate: FM/UL/CE certified
    1. Grooved Equal Tee View More
    2. Grooved Equal Tee The grooved ends are connected to the pipe using couplings for fluid distribution to provide the change in direction, and adapt sizes or components.
      Available sizes
      Available sizes: 1 inch~12 inch |DN25~DN300
      Working pressure
      Working pressure: 300 PSI
      Certificate
      Certificate: FM/UL/CE certified
    1. Grooved Reducing Tee View More
    2. Grooved Reducing Tee Grooved reducing tee, named for its T-shaped configuration, has a branch outlet with a different size from the main outlet. Each end of the tee has a groove, allowing it to be quickly and easily connected to the pipeline using couplings or fittings.
      Available sizes
      Available sizes: 2×1 inch~10×4 inch |DN50×25~DN250×65
      Working pressure
      Working pressure: 300 PSI
      Certificate
      Certificate: FM/UL/CE certified
    1. Threaded Reducing Tee View More
    2. Threaded Reducing Tee Threaded reducing tee is a type of tee fitting where the size of branch pipe is smaller than the main pipe, and the branch connection is threaded.
      Available sizes
      Available sizes: 2×1 inch~10×4 inch |DN50×25~DN250×65
      Working pressure
      Working pressure: 300 PSI
      Certificate
      Certificate: FM/UL/CE certified
    1. Grooved Long Radius Equal Tee View More
    2. Grooved Long Radius Equal Tee Grooved long radius equal tee is a type of tee fitting where the main and branch pipe have the same size. The neck of the long radius equal tee is longer compared to a standard equal tee.
      Available sizes
      Available sizes: 1 inch~12 inch |DN25~DN300
      Working pressure
      Working pressure: 300 PSI
      Certificate
      Certificate: FM/UL/CE certified
    1. Grooved Bullhead Tee View More
    2. Grooved Bullhead Tee Grooved bullhead tee is a type of tee fitting where the size of branch pipe is larger than the main pipe. This grooved tee is used to connect pipes, change the directions of pipeline, and adjust the size of components.
      Available sizes
      Available sizes: 1 inch~12 inch |DN25~DN300
      Working pressure
      Working pressure: 300 PSI
      Certificate
      Certificate: FM/UL/CE certified
    1. Grooved Lateral Tee View More
    2. Grooved Lateral Tee Grooved lateral tee is a type of tee fitting with a specified angle between the branch pipe and the main pipe, allowing for a change in the direction of the main pipe.
      Available sizes
      Available sizes: 1 inch~12 inch |DN25~DN300
      Working pressure
      Working pressure: 300 PSI
      Certificate
      Certificate: FM/UL/CE certified
